element PhysicalSystem

diagram
namespace	http://www.opengis.net/sensorML/2.0
type	sml:PhysicalSystemType
properties	content  complex substGrp  sml:AbstractPhysicalProcess
children	gml:metaDataProperty gml:description gml:descriptionReference gml:identifier gml:name gml:boundedBy gml:location sml:extension sml:keywords sml:identification sml:classification sml:validTime sml:securityConstraints sml:legalConstraints sml:characteristics sml:capabilities sml:contacts sml:documentation sml:history sml:typeOf sml:configuration sml:featuresOfInterest sml:inputs sml:outputs sml:parameters sml:modes sml:attachedTo sml:localReferenceFrame sml:temporalReferenceFrame sml:position sml:components sml:connections
used by	complexType  PhysicalSystemPropertyType
attributes	Name   Type   Use   Default   Fixed   annotation id ID required         documentation The attribute gml:id supports provision of a handle for the XML element representing a GML Object. Its use is mandatory for all GML objects. It is of XML type ID, so is constrained to be unique in the XML document within which it occurs. definition anyURI
annotation	documentation A PhysicalSystem is an aggregate system that can include multiple components (both physical and non-physical) with explicit links between the outputs, inputs, and parameters of the individual components. In a PhysicalSystem, the spatial position of the System itself is relevant to its application.
source	<element name="PhysicalSystem" type="sml:PhysicalSystemType" substitutionGroup="sml:AbstractPhysicalProcess">   <annotation>     <documentation>A PhysicalSystem is an aggregate system that can include multiple components (both physical and non-physical) with explicit links between the outputs, inputs, and parameters of the individual components. In a PhysicalSystem, the spatial position of the System itself is relevant to its application.</documentation>   </annotation> </element>
